High Load 7002AC 15x32x9mm Angular Contact Ball Bearing

Panoramica del prodotto：

When your machinery demands reliable performance under combined radial and axial loads, the 7002AC angular contact ball bearing delivers exceptional capability in a compact 15x32x9mm envelope. Manufactured from high-carbon chromium bearing steel (GCr15) and featuring a precision 25° contact angle, this single-row bearing is engineered for applications where load direction and rotational speed both matter.

Caratteristiche principali:

• Combined Radial and Axial Load Capacity
  Unlike deep groove ball bearings that are primarily radial-load devices, the 7002AC is specifically engineered to handle simultaneous radial and axial loads. Questa funzionalità riduce il numero di cuscinetti necessari in un assieme e semplifica la progettazione meccanica.

• Capacità ad alta velocità
  The 7002AC is engineered for high-speed operation, with grease-lubricated limiting speeds of 19,000–26,000 RPM and oil-lubricated speeds up to 32,000 giri al minuto, depending on cage and lubrication configuration. This speed capability makes it suitable for high-frequency motors and precision spindles.

• High Rigidity Under Preload
  When properly preloaded, angular contact bearings provide significantly higher stiffness than deep groove bearings. The preload eliminates internal clearance, ensuring precise component positioning and minimal deflection under load—critical for machine tool spindles and precision positioning systems.

• Wide Precision Grade Availability
  The 7002AC is available in multiple precision grades—P0 (standard), P6, P5, and P4 (ABEC-7) —allowing engineers to select the accuracy level that matches their application requirements.

• Opzioni di sigillatura versatili
  Disponibile aperto, Z.Z (doppia schermatura metallica), e 2RS (doppia guarnizione in gomma) configurazioni, the 7002AC can be tailored to specific environmental requirements.

Applicazioni:

The 7002AC angular contact ball bearing is a versatile component trusted across numerous industries:

• Mandrini di macchine utensili:Used in CNC machine tool spindle systems, satisfying high-precision and high-speed working requirements. The bearing’s high rigidity and precision support accurate machining operations.
• Electric Motors and High-Frequency Motors:Used in motor rotor support positions, handling combined radial and axial loads in high-frequency motor applications.
• Pumps and Fluid Handling: Pompe dell'acqua, oil pumps, and other fluid transfer equipment rely on the 7002AC for reliable, continuous operation.
• Componenti automobilistici: Riduttori, sistemi di sterzo, and other critical automotive applications requiring reliable power transmission and support.
• Gas Turbines and Oil Pumps: Applied in gas turbines, oil pumps, compressori d'aria, and printing machines.
• Engineering Machinery: Used in construction machinery, metallurgy, mining, petroleum, macchinari, electric power, railways, and other industries.
• Speed Reducers and Gearboxes: General industrial gearboxes, planetary drives, and speed reducers use angular contact bearings for shaft support under combined loads.
